This versatile receiver works seamlessly with a wide range of single-color RF remotes. Users can configure flexible lighting layouts across multiple zones. For instance, you can control zones separately or synchronize them together instantly. Furthermore, each zone can host an unlimited number of receivers, which makes system expansion simple and cost-effective.
Flexibility remains a key advantage of the SIRS-E® system. Each individual receiver can pair with up to 8 different RF remotes simultaneously. Consequently, multiple users can adjust the same lighting zone from different locations in a room. Additionally, you can connect the receiver to a compatible WiFi transmitter. This setup allows full smartphone control using dedicated iOS or Android apps.
Smooth performance ensures exceptional light quality in any application. The internal dimming engine provides flicker-free brightness adjustments from peak output down to subtle low-light levels. Therefore, your space receives clean, continuous illumination without eye strain or video interference.
Finally, the unit supports global radio frequency options. Depending on your region, you can select operating frequencies at 869.5MHz, 434MHz, or 916.5MHz. Overall, the SIRS-E® Universal RF Receiver combines heavy-duty power handling with smart wireless control for precision single-color lighting projects.
Technical Specifications:
- Input Voltage: 12-48VDC
- Output Current: 1x8A@12-36VDC; 1x4A@48VDC
- Output Power: 1x(96-288)W@12-36VDC; 1x192W@48VDC
- Output Type: Constant Voltage
- Dimensions (mm): 95 L x 37 W x 20 H
- Radio Frequency: 868MHZ / 869.5MHz / 916.5MHz / 434MHz
- Waterproof Grade: IP20
Compatible
SIRS-E® RF Wireless Remote Single Color
The SIRS-E® RF Wireless Remote offers 1-zone control for single-color LED lighting in residential and commercial areas.
