Made in USA AlphaSpec™ CV Series 240 LEDs per meter White LED Tape
AlphaSpec™ sets a new standard in the specification lighting market and is proudly Made in the USA. When paired with the correct channel and lens, it achieves full diffusion for a completely spotless appearance—ideal for high‐end architectural and commercial applications. Despite its slim 12 mm width, AlphaSpec™ incorporates a fixed density of 240 LEDs per meter, ensuring consistent and uniform illumination.
Flexible LED Options
To meet diverse design requirements, AlphaSpec™ offers six proprietary 2835 LED selections under the ChromaSure™ portfolio. Each option is engineered with unique performance characteristics, such as chromaticity, efficacy, and lumen output. This flexibility gives designers and specifiers the ability to match the right LED to the right project.
Configurable Performance
AlphaSpec™ supports variable LED segment configurations as well as multiple luminous output options. This allows you to carefully balance brightness levels with power consumption, ensuring optimal performance without compromising energy efficiency.
Precision Lighting Control
With a wide range of CCT (Correlated Color Temperature) selections, AlphaSpec™ enables fine-tuned control over ambiance. Whether the project calls for warm, inviting tones or bright, high-clarity illumination, the series provides precise adjustability for any environment.
Quality and Reliability
Backed by a 7-year limited warranty, AlphaSpec™ is designed and manufactured in America for the American market. This ensures not only high product quality but also localized support and compliance with relevant U.S. standards.
BAA/BABA Compliance
AlphaSpec™ meets Buy American Act (BAA) / Build America, Buy America (BABA) requirements through domestic assembly, using globally sourced PCB boards and LED chips. Final qualification for full compliance is subject to an approved non-availability exemption for these imported components. As of March 2025, no domestically manufactured equivalents are available.
Made in USA AlphaSpec™ Product Link
-
AlphaSpec™ CV Series
SKU LED/Seg SDCM LED Efficacy CCT lm/ft IP Rating Length Input Voltage Info Pack Action S240-63U22-xxx-xxxx
6 3 Ultra 2200K 100-1000 IP40, IP67 16.4 ft (5m), 100 ft (30m) 24V DC PDF S240-63U27-xxx-xxxx
6 3 Ultra 2700K 100-1000 IP40, IP67 16.4 ft (5m), 100 ft (30m) 24V DC PDF S240-63U30-xxx-xxxx
6 3 Ultra 3000K 100-1000 IP40, IP67 16.4 ft (5m), 100 ft (30m) 24V DC PDF S240-63U35-xxx-xxxx
6 3 Ultra 3500K 100-1000 IP40, IP67 16.4 ft (5m), 100 ft (30m) 24V DC PDF S240-63U40-xxx-xxxx
6 3 Ultra 4000K 100-1000 IP40, IP67 16.4 ft (5m), 100 ft (30m) 24V DC PDF S240-63U50-xxx-xxxx
6 3 Ultra 5000K 100-1000 IP40, IP67 16.4 ft (5m), 100 ft (30m) 24V DC PDF S240-63U65-xxx-xxxx
6 3 Ultra 6500K 100-1000 IP40, IP67 16.4 ft (5m), 100 ft (30m) 24V DC PDF S240-83U22-xxx-xxxx
8 3 Ultra 2200K 100-1000 IP40, IP67 16.4 ft (5m), 100 ft (30m) 24V DC PDF S240-83U27-xxx-xxxx
8 3 Ultra 2700K 100-1000 IP40, IP67 16.4 ft (5m), 100 ft (30m) 24V DC PDF S240-83U30-xxx-xxxx
8 3 Ultra 3000K 100-1000 IP40, IP67 16.4 ft (5m), 100 ft (30m) 24V DC PDF S240-83U35-xxx-xxxx
8 3 Ultra 3500K 100-1000 IP40, IP67 16.4 ft (5m), 100 ft (30m) 24V DC PDF S240-83U40-xxx-xxxx
8 3 Ultra 4000K 100-1000 IP40, IP67 16.4 ft (5m), 100 ft (30m) 24V DC PDF S240-83U50-xxx-xxxx
8 3 Ultra 5000K 100-1000 IP40, IP67 16.4 ft (5m), 100 ft (30m) 24V DC PDF S240-83U65-xxx-xxxx
8 3 Ultra 6500K 100-1000 IP40, IP67 16.4 ft (5m), 100 ft (30m) 24V DC PDF For Mobile display legend – Above table title – SKU, LED/Segment, SDCM, LED Efficacy, CCT, lm/ft, IP Rating, Length, Voltage, IES File, Info Pack, Button
Notes: 4IP – Varies on environment application, indoor or outdoor. 5IP67 only on 16.4’ (5m).Delivering proven LED strip lighting with no electrical, chromatic, or color rendering issues. Our unwavering focus on stability, efficiency, and performance sets the benchmark in linear LED and lighting control solutions.
