3528 SMD VAR White LED Waterproof Strip RF Kit 2800-12000k 10m

$405.00 $318.00

Condition: New


SKU: LED-WVAR-PK16 Categories: , Brands: .

Product Description

3528 SMD Var White LED Waterproof Strip DMX Kit, 2800-12000k 5m 16.4ft 120/m

Package Includes:

Product Features:

  • High Brightness, Single color and changing color
  • High luminance efficiency and low power consumption
  • Hours Maintenance – Over 100,000 hours of estimated life
  • Easy Installation, 3M Self adhesive back side
  • Matched Joint connector and direct soldering
  • The flexible LED strip can be divided into 10cm (Approx. 4 inches)segment!
  • 1 year limited warranty





 “10cm Segment”





Applications:

  • Ideal for in advertisement and cabaret, cabinet, furniture, landscape and architectural lighting.  This include Cove, edge and Contours lighting.
  • The flexible LED strip with self-adhesive back nearly sticks to every kind of underground.
  • Easy installation dedicated for room- and deco-light!
  • Signs

Product Details:

  • Standard: 1 Reel / 5 Meters
  • Usage: Decoration
  • Protection Level: Non-Waterproof
  • Power Source: DC
  • Input Voltage: 12V
  • Emitting Color: Cold to Warm White
  • Diffuser: Tempered Glass
  • Base Material: Aluminum
  • Electric Current: DC
  • Certification: CE



Parameters

Symbol

Absolute Maximum Rating

Unit

Foward Current

IF

Max 400

mA

Power Dissipation

PD

4.8

W

Electrostatic Discharge

ESD

1000

V

Operating Temp.

Topr

-25~+60

C

Storage Temp.

Tstg

-40~+80

C



Parameters

Symbol

Condition

Min

Type

Max

Unit

Forward Voltage DC

VF

IF=400mA

12

V
Dominant Wavelength

λD

IF=400mA —- nm
Color Temperature

Tc

IF=200mA

2500

2700 K

Color Temperature

Tc

IF=200mA

11000

12000 K
Luminous Flux (WW)

ψV

IF=200mA

90

110 lm
Luminous Flux (RW)

ψV

IF=200mA

120

150 lm
50% Power Angle 2 ⁰ 1/2 IF=400mA 120 deg



Features RGB LED DMX Controller 2:

  • Meets DMX512/1990
  • 256-level brightness, full-color control
  • 3 output CH., can drive 5A (Each CH.)
  • With control system, can express perfect effect
  • Can drive 1~3 channel of each lamp
  • Can set the DMX addess freely
  • Modularizing, can be combined with LED module neatly
  • Can be custom-made



Tech. Characteristics:

  • Decode CH. : 1~3
  • Input Signal : DMX-512/1990 digital signal
  • Output Signal : 0~24V PWM signal,can drive 5A (Each CH.)
  • Power Supply : DC , +12~25V
  • Power Dis. :
  • Power Output : 180W/12VDC 240W/24VDC
  • Operating Temp. : 0~70°C
  • Size : 175(mm)*45(mm)*35(mm) , can be custom-made
  • Weight : ≤300g
